Cricut Design Space Terminology for Beginners
When it comes to getting started with a Cricut machine and the Design Space software it can be daunting trying to figure out what all the functions and terms. Even though you are anxious to use all those wonderful craft materials, before jumping into tutorials it can be helpful to familiarize yourself with all the terminology that Cricut uses.
Below you will find 40+ terms and what they mean when working inside Design Space. PLUS at the bottom of this post, you can download a free printable PDF to refer back to anytime as you begin to master your Cricut!
When two or more items are selected on the canvas, this function aligns them according to the selection of center, left, right, top, bottom, etc.
The attach tool has a two-fold purpose. It allows you to hold images in place
relative to each other on the cutting mat and also lets you attach score lines and text to images.
Arranging an image allows you to move it in front of, behind, or in between
other image layers present on the canvas.
The canvas is the Design Space visual workspace where you will design and
arrange your vectors or prints and access all the tools.
Color Sync panel helps by consolidating the colors of one project to reduce the number of colored materials you need to use when cutting a project.
The Contour tool lets you hide portions of an image layer quickly so that they won’t cut out – creating a new image result.
Cricut Cut/Go Button
The cut button refers to the Cricut logo button to the left side on your machine. Press this button to initiate a cut.
Cut lines are the shape’s outlines or each layer’s outline that will cut when
The Cut Screen a.k.a Make it Button
The screen that loads after you click the Make It button at the top right-hand side. This screen will be present when the machine is cutting designs out.
The cutting mats are what you will stick your material on to load into your
Cricut machine. Use light blue for paper, pink for fabric, green for vinyl and other general materials, and purple for wood or metal.
Access my craft freebies and SVG cut files here!
Delete will remove an image permanently from the canvas.
Deselect all items currently selected on the canvas.
Cricut’s cloud-based software for designing and doing your projects.
Download it at https://design.cricut.com/
Draw lines or Writing style will be the line-type when using a pen to write
script or draw an image.
Clone and duplicate any image on the screen.
The edit function allows you to cut, copy and paste any object on the canvas.
Filling an image means a pattern or printed color is placed inside an image present on the canvas.
Flattening means that a current vector, which has two or more layers, can be turned into a printable image for the Print Then Cut feature.
Gain access to all my SVG cut files and templates here!
Flipping an image will turn it 180 degrees horizontally or vertically.
Group command enables multiple image layers or text present on the canvas to be selected and move at one time as one object so as not to affect their layout.
Images or Image Library
Images that you can buy or use for free in the Cricut membership or freebie section of Design Space.
JPG & PNG Files
These are image files that will end in either .jpeg or .png. These are uploaded in Design Space for the Print and Cut feature.
Layers refer to one unified image on the canvas. Multiple images can be “layered” together or moved backward and forward using Arrange.
The line type is the action that will occur when the Cricut machine creates – cut, draw, score, engrave, perforate, wavy edge, and deboss.
The load button is the double arrow button present next to the cut button on the machine. Pressing the double arrow button loads and unloads the cutting mat from the machine.
Material settings are present in Design Space or on the dial or the Explore machine. These are key to setting the pressure that the blade will use on the selected material.
Mirroring reverses an image so that it is backward. Mirroring is necessary when working with heat transfer vinyl (a.k.a iron-on) so that the finished project will read the correct direction. Use the mirror toggle on the cut screen to set this.
No fill means that there is no print pattern present on the vector selected on the canvas.
Print Then Cut
Print Then Cut is a flattened image on the canvas often with a pattern, which is sent to your home printer via Design Space and then an outline of that printed image cut by the machine.
Redo a recently undone action when working in Design Space.
Guides that are printed when using the Print and cut function. Cricut reads these as a means of cutting the flattened image correctly.
Rotate any image 360 degrees on the canvas.
Score lines are creasing the paper or material used with a scoring tool or wheel.
The select all button allows you to select any images presently visible on the canvas.
The size is the dimensions of an image or object when selected on the canvas.
Shapes button allows you to insert any basic geometric shape onto your canvas. These are free.
The slice tool created new cut paths from two images. It will result in three or more new shapes that present as new layers. Select only two layers to make this tool usable.
SVG (a.k.a Scalable Vector Graphic)
An SVG cut file is a vector file that can be scaled larger or small and retain its resolution. SVG files are made up of lines that consist of infinite dots to achieve this flexibility. Use SVG cut files to cut colored materials on your Cricut and arrange a final layered design.
Text or Font
Text is how you can type words and customize your writing with unique fonts and scripts within Design Space. Text can be cut or drawn according to the line-type set.
Undo a recent action in Design Space.
Ungrouping enables you to move each layer of a vector on the canvas individually from its counterparts.
Upload is adding your own vector, print or pattern fill images to Design Space.
The process of removing unwanted excess vinyl from a cut design.
The weld tool enables you to combine two single shapes or text into one new seamless shape, eliminating unwanted cut lines. Welding is often used with text to create seamless cursive words.
New to Cricut?
Are you ready to Master your Cricut, discover new hobbies and skills, and design for yourself?! Be sure to join my FREE masterclass on the 3 biggest beginner Cricut crafter misconceptions and how to fix them!
This masterclass is for you if you…
…own a Cricut machine but feel like you have no clue what you are doing!
…wish you could design your own project files.
…are tired of searching Pinterest and Google for answers
…craft several times a week, and want to personalize your crafts, home or event decor or maybe even want to sell your crafts!
Grab your free PDF printable below to keep all these functions straight!
